Is it possible to mix standard AXL F/ AXL SE hardware with the AXC F IL adapter with inline hardware? For example I have 4 smart elements to the right of the controller, then IL adapter with a PWM and CNT module attached.
It appears that PLCnext does not allow this when choosing the adapter in the hardware extension settings as the Axioline F bus section under the plant window is replaced by the AXL F IL ADAPT bus.
Is there a way to read the Axioline hardware as profinet (without the use of a BK) while having the AXL F IL Adapter connected?
Is it possible to mix standard AXL F/ AXL SE hardware with the AXC F IL adapter with inline hardware?No. The local bus can only be Axioline or Interbus, but never both.
Is there a way to read the Axioline hardware as profinet (without the use of a BK) while having the AXL F IL Adapter connected?No, this is not possible.
Is an AXC XT IB (hardware extension) a feasible option?
Cheers
The AXC XT IB can communicate with Inline I/O that is connected to an Interbus bus coupler, but in that case you could use a Profinet bus coupler instead of the Interbus bus coupler and save the cost of the AXC XT IB module.
