Is there a more complete list of AxioLine (LocalBus) Diagnostics in the WBM ? I did go to the (IBS SYS DIAG DSC UM E) manual as suggested in the InfoCenter, but I could not find many of the codes I have been noticing: I have seen other Codes also that I cannot locate. …e.g. 0x0280 / 0x0284 / 0x0080… Thank you for your assistance ! Peter
Hello Peter, The Status register should be analysed bit by bit.
Thats why not every code combination can be found in the Documentation.
Page 12 of the Axl F sys diag sheet.
um_de_axl_f_sys_diag_8663_de_03 (5).pdf
um_en_axl_f_sys_diag_8663_en_03.pdf
Thank you - I hope you have a great day ! Peter
