AXC F 2512 and BTP 2043W

PLCnext Engineer
1

Hello, I would like to ask how can I display the visualization created in PLCnext Engineer running in AXC F 2152 on the BTP2043W touch panel? Thank you

2

Hello, The eHMI screens developed in PLCnext Engineer are designed to be displayed in a web browser. My understanding is that the BTP2043W does not include a web browser, or at least not by default. Instead, that touch-panel starts the Visu+ runtime. So, that panel is intended to run a HMI project developed using Visu+ or Visu+ Express software, not PLCnext Engineer. Please let us know if you have any other questions. ~ Martin.

3

And would I be able to install a browser there? If possible, what would you recommend? Thank you. Jaro.


4

Hi Jaro, The BTP2043W is an embedded device running a custom operating system, and is designed to boot directly into the Visu+ runtime. I don’t know if it is possible to modify this behaviour to launch a browser instead. Since this device is not part of the PLCnext Technology ecosystem, you will need to check this with the technical support people in your local Phoenix Contact office, who should be able to give you advice on this product. Regards,

Martin.
